Specs
- Width 84.83
- Height 48.75
- Length 77.11
- Curb Weight 1400
- Deck Style Floating Deck
- Deck Style Description Full-floating UltraCut Series 6. Side discharge standard, with molded discharge chute and option to mulch.
- Width / Cutting Deck 72"
- Deck Construction 10-gauge top that is formed and continuously seam welded, 7-gauge side skirt
- Cutting Heights 1.5" (3.8 cm) to 5.0" (12.7 cm) in 0.25" (0.64 cm) increments adjustable from operator’s platform.
- Blade Tip Speed Approximately 18,500 fpm.
- Blades 3 Blades at 24.50" Length
- Engine Brand Kawasaki
- Engine Model FX1000V
- Engine Displacement 999
- Fuel System Carbureted
- Speed Infinitely variable speed selection 0–12.0 mph (19.3 kmph) forward, 0–5.0 mph (8.0 kmph) reverse
- Engine Series V-Twin
- Engine Speed 3,600 rpm
- Fuel Capacity 14-gallon (53.0-L), Dual fuel tanks on RH and LH side.
- Air Filter Heavy-duty canister air filtration system
- Drive Description Two Hydro-Gear 16 cc pumps powering two Hydro gear 17.8 cubic inch motors.
- PTO Engagement Warner 250 ft-lb clutch
- Fuel Type Gas Carbureted
- Drive System HYDRO
- Drive Wheel Release Allows unit movement without engine running.
- Fuel Indicator Yes - Float Gauge
- Deck Lift Single point HOC; with mechanical lift-assist springs.
- Carb Compliant NO
- Safety Package Operator Presence Controls (OPC) with safety interlock system indicators
- UPC 193308241357
- Steering Control Twin levers with center fixed reference bar for ease of control forward and reverse
- Front Caster Tires 15 x 6.0-6, smooth-tread, semipneumatic tires with tapered roller bearings.
- Drive Tires 24x12-12 Hoosier Grass Master
- Parking Brake Lever-actuated internal motor brake
- Tractor Frame Welded, heavy-duty 1.5" x 3.0" tubular steel.
- Blade Spindles No maintenance, sealed and nongreasable spindles; 7.75" diameter cutter housing with 1.75" diameter splined blade driver 1.0"-diameter spindle shaft.
- Cup Holder Yes
- Electrical 12-volt battery with 30-amp alternator.
- Standard Features Enhanced Engine Hour Meter
